Silicon Steel Slitting Line

This silicon steel slitting line is used for slitting silicon steel coils or CRGO coils. It is necessary equipment in the manufacturing of transformer industry and related electric industries.

1. The slitting thickness of automatic steel coil slitting machine ranges from 0.15mm to 0.5mm.
2. The suitable width for this slitting line is from 1000mm to 1250mm.
3. The steel slitting line has high precision and high working speed.
4. Its slitting speed can reach 60m/min and the strip precision can be up to 0.1mm.

1. There should be 2 to 5 workers in the line. And the other people should be stay far away from the silicon steel slitting line.
2. Yellow characters should be installed around the equipment to indicate off-limits place on railings.
3. Please remember to lubricate gears and chains on this steel slitting line.
4. Add the coil properly in order to keep the weight balanced. The coil car can reset only after fix and expand the coil into decoiler tightly.
5. First press the coil head by traction roll, and then open the package of the coil, to prevent the coil head bounced off.
6. Operators shall be banned to stand on the coil when machine running.
7. Moving coil directly by hand is forbidden.
8. When silicon steel slitting line has any problem, stop and check the machine immediately.
9. Do not remove or change circuit. If there is any problem, please consult professional technicians.

Silicon Steel Slitting Line

Maintenance and Lubrication
First, you should check machine units whether loosen or damaged. The oil pipes must be smooth and be filled oil regularly. After work you must be sure that the parts are normal, such as electrical parts, hydraulic parts, and pneumatic parts. After work main power should be cut off, and the automatic steel coil slitting machine should be cleaned up;

Packaging and Transportation
1. This steel slitting line is suitable for sea shipping by container.
2. This automatic steel coil slitting machine is usually nude packaging with cable wire and wooden block fastening it without special requirement.
3. All gadgets should be placed in accessory box.

Parameters of Silicon Steel Slitting Line
Item Value
Steel thickness 0.15 to 0.5mm
Decoiling expansion range Φ480 to Φ520mm
Max. sheet 1250mm
Coil weight 5 to 8 ton
Slitting shaft Φ125mm
Blade outer diameter Φ250mm
Slitting strip 20 to 1250mm
Slitting speed 50 to 120m∕min
Burr ≤0.02mm
Straightness ≤0.2mm/2m
tolerance ±0.1mm
Slitting blade 12 sets
Power consumption 55kW
Line dimension 12.6m × 6.5m × 2m
Gross weight about 20 ton
Power supply 380V .AC. 50Hz
